Configuration file examples 313
BC cascaded connection command examples
Commands from HOSTA, Instance 0 shown on page 311
The following examples employ RM commands from HOSTA, Instance 0.
• When the command execution environment is not set, set the instance
number. (If C shell)
# setenv HORCMINST 0
(Windows NT/2000/2003) set HORCMINST=0
• Set the HORCC_MRCF environment variable. (If C shell)
# setenv HORCC_MRCF 1
(Windows NT/2000/2003) set HORCC_MRCF=1
• Designate group names (Oradb and Oradb1) and a local instance
P-VOL:
# paircreate -g Oradb -vl
# paircreate -g Oradb1 -vr
This command begins a pair coupling between the four pairs of
volumes designated as Oradb and Oradb1 in the configuration
definition file.
• Designate a group name and confirm pair states:
# pairdisplay -g oradb –m cas
Group PairVol(L/R) (Port#,TID,LU-M), Seq#, LDEV#..P/S, Status, Seq#, P-LDEV# M
oradb oradev1(L) (CL1-A, 1, 1-0) 30053 266..P-VOL PAIR 30053 268 -
oradb oradev1(R) (CL1-D, 2, 1-0) 30053 268..S-VOL PAIR ----- 266 -
oradb1 oradev11(L) (CL1-D, 2, 1-1) 30053 268..P-VOL PAIR 30053 270 -
oradb2 oradev21(R) (CL1-D, 2, 1-2) 30053 268..SMPL ---- ----- ---- -
oradb oradev2(L) (CL1-A, 1, 1-0) 30053 267..P-VOL PAIR 30053 269 -
oradb oradev2(R) (CL1-D, 2, 2-0) 30053 269..S-VOL PAIR ----- 267 -
oradb1 oradev12(L) (CL1-D, 2, 2-1) 30053 269..P-VOL PAIR 30053 271 -
oradb2 oradev22(R) (CL1-D, 2, 2-2) 30053 269..SMPL ---- ----- ---- -
