7. 15
MODEL6300
Section 7 Integration value measurement MODEL6300
7-5-3 Parameters Recorded
Depending on the wiring configuration chosen, the following parameters are
recorded:
Parameters recorded(measured or computed)
Voltage
(RMS)
Vi :Instantaneous value of phase i at end of interval
Vi max : Max. value of phase i during interval
Vi avg
: Average value of phase i during interval
Current
(RMS)
Ai : Inst value of phase i at end of interval
Ai max : Max. value of phase i during interval
Ai avg
: Average value of phase i during interval
Active
power
P : Inst value of total active power at end of interval
P max : Max. value of P during interval
P avg : Average value of P during interval
Pi : Instantaneous value of phase i at end of interval
Pi max : Max. value of phase i during interval
Pi avg
: Average value of phase i during interval
Reactive
power
Q : Inst value of total reactive power at end of interval
Q max : Max. value of Q during interval
Q avg : Average value of Q during interval
Qi : Instantaneous value of phase i at end of interval
Qi max : Max. value of phase i during interval
Qi avg
: Average value of phase i during interval
Apparent
power
S : Inst value of total apparent power at end of interval
S max : Max. value of S during interval
S avg : Average value of S during interval
Si : Instantaneous value of phase i at end of interval
Si max : Max. value of phase i during interval
Si avg
: Average value of phase i during interval
Power
factor
PF : Inst value of Power factor of whole system at end of interval
PF max : Max. value of PF during interval
PF avg : Average value of PF during interval
PFi
: Instantaneous value of phase i at end of interval
PFi max : Max. value of phase i during interval
PFi avg : Average value of phase i during interval
Frequency
f : Inst value of Frequency of V1 at end of interval
f max : Max. value of f during the interval
f avg : Average value of f during the interval
Neutral
current
In : Current on neutral conductor at end of interval
In max : Max. value of In during the interval
In avg
: Average value of In during the interval
Active
electrical energy
(consumption)
+WP : Total active electrical energy(consumption)
+WPi : Active electrical energy per phase (consumption)
Active
electrical energy
(regenerating)
-WP : Total active electrical energy (regenerating)
-WPi : Active electrical energy per phase (regenerating)
Active
electrical energy
(overall)
#WP : Total active electrical energy(overall)
#WPi : Active electrical energy per phase(overall) during interval
