6. 3
MODEL6300
Section 6 Instantaneous value measurement MODEL6300
‣‧ • ⁈ ‧ • ⁈ ‥ • • ⁈ ‥ • • ⁈ • • ⁈ • • ⁈ ‣ ⁂ ‣ ⁂․ ⁉ ․ ⁉ ‣ ⁂ ‣ ⁂‥ ⁉ ‥ ⁉ ‥ ⁂ ‥ ⁂‥ ⁉ ‥ ⁉ ‥ ⁂ ‥ ⁂… ⁉ … ⁉
‧ ″ ‧ ″ ‣ • ‣ •″ ․ • ″ ․ • ″ ‧ • ″ ‧ • ″ ‣ • ‣ •• ″ • ″ ․• • ″ • • ″ ‧ • • ‧ • •″ ‣ • • • ″ ‣ • • • ″
Ɣ Keys
Key Description
START/STOP key No use
BACKLIGHT key Switches on/off the backlight of the LCD.
UP cursor key
DOWN cursor key
Changes the display contents.
Selects the row to be changed while in custom
display mode.
LEFT cursor key
RIGHT cursor key
Changes the display contents.
Selects the parameter (V, A etc.) to be displayed
while in custom display mode
ENTER key
Selects/ Enters custom display mode.
Confirms the deletion of a file in the internal
memory.
ESC key Cancels a setting in custom display mode.
Holds the indicated value on the LCD.
DATA HOLD key
Pressing this key for at least 2 sec. disables all
key operations to prevent operation mistake
during a measurement.
SAVE key Saves the measured data.
Ɣ Indication at no input
When no voltage and current are input, indication on the LCD will be as
follows. Refer to “6-5-2 Over-range indication/ Bar indication” in this
manual.
‣ ‧ • ⁈ ‥ • •⁈ • •⁈ ‣ ⁂․⁉ ‣⁂‥ ⁉ ‥ ⁂‥ ⁉ ‥⁂… ⁉
‧ ″ ‣• ″ ․ •″ ‧• ″ ‣ • • ″ ․ • •″ ‧ • • ″ ‣ • • • ″
