8. 19
MODEL6300
Section 8 Demand value measurement MODEL6300
Ɣ File format and name
Measured data is saved in CSV format, and the file name is assigned
automatically.
File name: 3 F I L E 0 0 1 . C S V
1: Instantaneous value File number (001 ~ 999)
measurement FILE : CF card
2: Integration measurement DATA : Internal memory
3: Demand measurement
Ɣ Example of measured data
Wiring: 3P3W Wiring “Setting 01”
Volt Range: 600V Voltage range “Setting 02”
Current Range: 500A Current range “Setting 03”
Sensor Type: 500A Clamp sensor “Setting 04”
VT ratio: 1 VT ratio “Setting 05”
CT ratio: 1 CT ratio “Setting 06”
Interval 30min Demand interval “Setting 13”
START 2004/03/23_08:30:00 Demand start time & date
DATE TIME
ELAPSED
TIME
V1 V2 V3 Q3 f In
2004/03/23 09:00:00 00000:30:00
2004/03/23 09:30:00 00001:00:00
V1
max
V2
max
V3
max
Q3
max
F
max
In
max
V1
avg
V2
avg
V3
avg
Q3
avg
F
avg
In
avg
+
WP
+
WP1
+
WP2
-
WP3
#
WP
#
WP1
#
WP2
#
WP3
+
WS
#
DEM2
#
DEM3
TARGET
Data will be displayed in index format.(e.g. 110.5kW, “1.105E+5”.)
1
2
n
