6. 17
MODEL6300
Section 6 Instantaneous value measurement MODEL6300
6-5 Ranges and Over-range indication
6-5-1 Ranges
The settings determine the range for each measurement parameter, namely:
Voltage range (“Setting 02”), Current range (“Setting03”), VT ratio (“Setting
05”) and CT ratio (“Setting 06”). (Fixed range)
Ɣ Voltage V: V(average of each phase), V1/V2/V3 (each phase), max 4 digits
150/300/600V range
Voltage range x VT ratio x 120% Digit & Decimal point position
180 ~ 999.9 V 999.9 V
1k ~ 9.999 kV 9.999 kV
10k ~ 99.99 kV 99.99 kV
100k ~ 999.9 kV 999.9 kV
1M ~ 7.2 MV 7.200 MV
When the value of (Voltage range x VT ratio x 120%) exceeds 9999, the
decimal point moves one place to the right.
Ɣ Current A: A(average of each phase), A1/A2/A3 (each phase), max 4 digits
50A Clamp sensor : 5 / 10 / 20 / 50A range
100AClamp sensor : 10 / 20 / 50 / 100A range
200AClamp sensor : 20 / 50 / 100 / 200A range
500AClamp sensor : 50 / 100 / 200 / 500A range
1000AClamp sensor : 100 / 200 / 500 / 1000A range
3000AClamp sensor : 1000 / 3000A range
Current range x CT ratio x 120% Digit & Decimal point position
6 ~ 9.999 A 9.999 A
10 ~ 99.99 A 99.99 A
100 ~ 999.9 A 999.9 A
1k ~ 9.999 kA 9.999 kA
10k ~ 99.99 kA 99.99 kA
100k ~ 999.9 kA 999.9 kA
1M ~ 9.999 MA 9.999 MA
12 MA 12.00 MA
When the value of (Current range x CT ratio x 120%) exceeds 9999, the
decimal point moves one place to the right.
