MODEL6300 Section 7 Integration value measurement
Section
7
7-1 Survey initiation
There are two ways of starting a survey.
(1) Manual operation
Pressing
START/STOP key on Wh range for 2 sec. or more starts
measurement.
(2) Automatic operation (presetting the time and date)
Set the start time and date on the
SET UP range (“Setting 10”), and then
press START/STOP key on Wh range. The instrument goes into stand-by
mode, and the measurement starts at the preset time and date.
Ɣ Manual measurement
* Press the
START/STOP key on Wh range for 2 secs. or more.
* The file number screen is displayed for about 2 sec. (a file is opened),
followed by the measurement screen. The survey then starts.
At this time, LED status indicator is on. In addition, and (**)
marks appear on the measurement screen.
(**) When data is to be saved to the CF Card, mark appears. When
data is to be saved to the internal memory, mark appears.
(See “Setting19”.)
File number screen
(displayed for about 2 sec.)
Measurement screen
‣‧ • ⁈ • ⁈ ‥ • • ⁈ ‥ • • ⁈ • • ⁈ • • ⁈ ‣ ⁂ ‣ ⁂․⁉ ‣ ⁂ ‣ ⁂‥ ⁉ ‥ ⁉ ‥ ⁂ ‥ ⁂‥⁉ ‥ ⁂ ‥ ⁂… ⁉ … ⁉
‧ ″ ‧ ″ ‣ • ″ ‣ • ″ ․ • ″ ․ • ″ ‧ • ″ ‧ • ″ ‣ • • ″ ‣ • • ″ ․ • • ″ ․ • • ″ ‧ • ‧ •• ″ • ″ ‣ • • • ″ ‣ • • • ″
‣‧ • ⁈ ‧ • ⁈ ‥ • • ⁈ ‥ • • ⁈ • • ⁈ • ⁈ ‣ ⁂ ‣ ⁂․⁉ ‣ ⁂ ‣ ⁂‥ ⁉ ‥ ⁉ ‥ ⁂ ‥ ⁂‥⁉ ‥ ⁂ ‥ ⁂… ⁉ … ⁉
‧ ″ ‧ ″ ‣ • ″ ‣ • ″ ․ • ″ ․ • ″ ‧ • ″ ‧ • ″ ‣ • • ″ ‣ • • ″ ․ • • ″ ․ • • ″ ‧ • ‧ •• ″ • ″ ‣ • • • ″ ‣ • • • ″
LED status indicator
is on.
