Section 6 Instantaneous value measurement
Section
6
‣‧ • ⁈ ‥ • • ⁈ • • ⁈
‣ ⁂․⁉ ‣ ⁂‥ ⁉ ‥ ⁂‥⁉ ‥ ⁂… ⁉
‧ ″
‣ • ″
․ • ″
‧ • ″
‣ • • ″ ․ • • ″ ‧ •• ″ ‣ • • • ″
‣‧ • ⁈ ‥ • • ⁈ • • ⁈
‣ ⁂․⁉ ‣ ⁂‥ ⁉ ‥ ⁂‥⁉ ‥ ⁂… ⁉
‧ ″
‣ • ″
․ • ″
‧ • ″
‣ • • ″ ․ • • ″ ‧ •• ″ ‣ • • • ″
Ɣ File format and name
Data is saved in CSV format, and the file name is assigned automatically as
follows:
File name:
1 F I L E 0 0 1 . C S V
1: Instantaneous value
File number (001 ~ 999)
measurement
FILE
: CF card
2: Integration measurement
DATA : Internal memory
3: Demand measurement
Ɣ Example
After downloading the file (CF card or internal memory), if the file is opened
with a spreadsheet application software( using CSV format, eg Microsoft
Excel), the spreadsheet will be as follows:
Wiring: 3P4W
Wiring “Setting 01”
Volt Range:
300V
Voltage range
“Setting 02”
Current Range:
200A
Current range
“Setting 03”
Sensor Type:
500A
Clamp sensor
“Setting 04”
VT ratio:
1
VT ratio
“Setting 05”
CT ratio:
1
CT ratio
“Setting 06”
DATE TIME
V1
V2
V3
A1
A2
A3
P
P1
P2
P3
2004/3/21
15:50:35
2004/3/21
16:51:21
PF
PF1
PF2
PF3
S
S1
S2
S3
Q
Q1
Q2
Q3
f In
*1: this is the data saved when
SAVE
key is pressed for the first time.
(i.e. when a file is opened).
*2: this is the second data point saved when the
SAVE
key is pressed again whilst
the file is still open.
*n: these are subsequent data points saved whenever the
SAVE
key is pressed
whilst the file is still open.
Data will be displayed in exponential format. (e.g. when V1 is 100.1V, “1.001E+2”).
