MODEL6300
8. 18
MODEL6300 Section 8 Demand value measurement
Section
8
8-6-3 Parameters recorded
Parameters recorded(measured or computed)
Voltage
(RMS)
Vi :Instantaneous value of phase i at end of interval
Vi max : Max. value of phase i during interval
Vi avg
: Average value of phase i during interval
Current
(RMS)
Ai : Inst value of phase i at end of interval
Ai max : Max. value of phase i during interval
Ai avg
: Average value of phase i during interval
Active
power
P : Inst value of total active power at end of interval
P max : Max. value of P during interval
P avg : Average value of P during interval
Pi : Instantaneous value of phase i at end of interval
Pi max : Max. value of phase i during interval
Pi avg
: Average value of phase i during interval
Skipped (See “7-5 Saving data” in this manual for further details.)
Apparent
electrical energy
(regenerating)
-WS : Total apparent electrical energy (regenerating) during interval
-WSi : Apparent electrical energy per phase (regenerating) during interval
Apparent
electrical energy
(overall)
#WS : Total apparent electrical energy(overall) during interval
#WSi : Apparent electrical energy per phase (overall) during interval
Reactive
electrical energy
(consumption)
+WQ : Total reactive electrical energy (consumption) during interval
+Wqi : Reactive electrical energy per phase (consumption) during interval
Ɣ Demand measurement:
Demand value
#DEM : Total demand value #DEMi : Demand value of each phase
TARGET : Target demand value
* i = 1, 2, 3
* max, avg mean max value and average value during an interval.
