6. 5
MODEL6300
Section 6 Instantaneous value measurement MODEL6300
Ɣ Single-phase 2-wire (3ch) “1P2W (3ch)”(15 screens)
Screen A Screen B Screen C Screen D Screen E Screen F Screen G
Upper V V V V
Middle A A1 A2 A3 Screen 1
Lower P P1 P2 P3
- - -
Upper P P1 P2 P3
Middle S S1 S2 S3 Screen 2
Lower PF PF1 PF2 PF3
- - -
Upper V A1 P1 PF1 S1 Q1 f
Middle - A2 P2 PF2 S2 Q2 - Screen 3
Lower - A3 P3 PF3 S3 Q3 -
Ɣ Single-phase 3-wire “1P3W”, Three-phase 3-wire “3P3W” (13 screens)
Screen A Screen B Screen C Screen D Screen E Screen F Screen G
Upper V V1 V2
Middle A A1 A2 Screen 1
Lower P P1 P2
- - - -
Upper P P1 P2
Middle S S1 S2 Screen 2
Lower PF PF1 PF2
- - - -
Upper V1 A1 P1 PF1 S1 Q1 f
Middle V2 A2 P2 PF2 S2 Q2 - Screen 3
Lower - - - - - - -
Ɣ Three-phase 4-wire “3P4W” (15 screens)
Screen A Screen B Screen C Screen D Screen E Screen F Screen G
Upper V V1 V2 V3
Middle A A1 A2 A3 Screen 1
Lower P P1 P2 P3
- - -
Upper P P1 P2 P3
Middle S S1 S2 S3 Screen 2
Lower PF PF1 PF2 PF3
- - -
Upper V1 A1 P1 PF1 S1 Q1 f
Middle V2 A2 P2 PF2 S2 Q2 In Screen 3
Lower V3 A3 P3 PF3 S3 Q3 -
NOTE
* Parameters on each screen can be changed.
Refer to “6-3 Customizing the display” in this manual.
