10. 11
MODEL6300
Section 10 Communication function/ Supplied software MODEL6300
(5) Buttons
“Send”
Can transfer the SET UP items for the instrument, which have been set
on your PC, to the instrument. Settings should be made according to each
use environment. After making necessary settings, click this button.
Then the settings will be reflected on the
SET UP range of the instrument.
“Confirm”
Can check the SET UP items for the instrument.
Clicking this button loads and displays the SET UP items for the
instrument. The set values before loading are overwritten.
Be sure to save the important settings prior to load other settings.
“Initial value”
Restores all settings to the initial value.
As to the initial value, refer to “Section 4: Settings” in this manual.
“Set Date/Time from PC”
Adjusts the time of the instrument to the time on your PC. Can set time and
date (hour & minute are settable) by clicking this button. Adjust the time on
your PC to the present time first.
“Save”
Can save the settings as configuration file. (*kps)
Setting corresponding to each environment can be saved.
If the configuration file is saved together with the recorded data,
record/measurement conditions can be checked as well.
“Configuration file”
Opens the saved configuration files. (*kps)
If the settings corresponding to an environment have been saved, you can
switch the setting to the proper one immediately.
If the configuration file is saved as conditions for record/measurement,
settings at that time can be checked as well.
“Exit”
Closes the setting screen.
NOTE
* For further details about each setting items, refer to “Section 4: Setting” in
this manual.
