6. 1
MODEL6300
Section 6 Instantaneous value measurement MODEL6300
6. Instantaneous value measurement
Set the Function switch to W range.
During Inst. value measurement, if the Function switch is set to a position
other than
W , it results in the following;
Wh range : No effect
DEMAND range : No effect
SET UP range : Change/ Confirm the settings
(see “Section 4: Settings”)
Ɣ Indications
Measurement/Calculation parameter Unit
Voltage (RMS) Vi : Voltage per phase(V1,V2,V3) V
Current (RMS) Ai : Current per phase(A1,A2,A3) A
Active power P : Total active power Pi : Active power per phase
Polarity: (no mark) consumption, - (minus) regenerating
W
Reactive power Q : Total reactive power Qi : Reactive power per phase
Polarity: (no mark) phase lag, - (minus) phase lead
Var
Apparent power S : Total apparent power Si : Apparent power per phase VA
Power factor
(cos I)
PF : Power factor of whole system Pfi : Power factor per phase
Polarity:(no mark) phase lag, - (minus) phase lead
PF
Frequency f : Frequency of V1 Hz
Neutral current In : neutral current (only at three-phase 4-wire) An
i = 1, 2, 3
Displayed parameters can be changed according to needs.
Refer to “6-3 Customizing display” in this manual.
NOTE
* Above parameters vary depending on each wiring configuration.
* If V1 is out of measuring range, other parameters may not be measured or
calculated.
* The chosen units for the power factor and neutral current are arbitrary.
