13. 1
MODEL6300
Section 13 Specification MODEL6300
13. Specification
13-1 General specification
Location for use In door use, Altitude up to 2000m
Temperature&humidity
Range
(guaranteed accuracy)
23ºC±5ºC/Relative humidity 85% or less
(no condensation)
Operating temperature &
humidity range
0ºC~50ºC/Relative humidity 85% or less
(no condensation)
Storage temperature &
humidity range
-20ºC~60ºC/Relative humidity 85% or less
(no condensation)
Measured line single-phase 2-wire (1ch ~ 3ch), single-phase 3-wire,
three-phase 3-wire, three-phase 4-wire
Withstand voltage AC5320V/ for 5 sec.
between (voltage input terminal) and (enclosures)
AC3320V/ for 5 sec.
between (voltage input terminal) and
(power supply, USB connector)
AC2710V/ for 5 sec.
between (power connector) and
(USB connector, current input terminal, enclosures)
Insulation resistance 50M ȍ or more / 1000V
between (voltage/ current input terminal,
power connector) and (enclosures)
Display Liquid crystal display (segment type)
Indication renewal every 1 sec.
Backlight Pressing the backlight key switches the light on/off.
(Light is automatically turned off after 5 minute.)
Rated AC
power supply voltage
100V ~ 240V ± 10% (45~65Hz)
10VA max.
Rated DC
power supply voltage
9V (Alkaline size AA battery (LR6) 1.5V x 6pcs)
Current consumption 180mA typ.
(7 hours continuous measurement/ at LR6 is used)
Applicable standard IEC 61010-1
Measurement CAT. III 600V, Pollution degree 2
IEC 61010-031, IEC 61326
Dimension 175(L) x 120 ( 㨃) x 65 (D) mm
Weight approx. 800g (including batteries)
