Summit T3‐16 PCI Express Multi‐Lane Protocol Analyzer User Manual
53
Chapter 5
Recording Options
5.1 Recording
Overview
After installing the software recording options should be set prior to recording. The
recording options define the behavior of the Summit T3‐16 during recording. You can
create, save and load previously saved recordings. This section explains how to define
recording options on the Summit T3‐16 Analyzer.
5.2 General
Tab
The Recording Options dialog is used to configure a recording.
To open the Recording Options window, click
or select the command
Setup > Recording Options.
Note:
There are separate sets of Recording Options for each Analyzer type. To set the Analyzer type,
select the appropriate platform from the Target Analyzer menu in the General tab of the
Recording Options.
The General tab displays options that affect all recordings (see
).
