Summit T3‐16 PCI Express Multi‐Lane Protocol Analyzer User Manual
35
Using the Menus
Teledyne LeCroy
4.5.6
Search Menu
Search Menu operations are only available when you are working with a CATC Trace file.
Packet Header
Opens the Packet Header bar, showing the Packet Header
information as it would be viewed in the specification.
Packet Data
Opens the Data Window for the current packet or transaction, with
the options: Hide, Save, Hexadecimal, ASCII, Decimal, Binary,
MSB Format, LSB Format, Big Endian, and Little Endian. Format Line
allows you to enter the number of bytes, words, or dwords per line.
Configuration
Space
Presents a list of Configuration Spaces. Clicking an item displays the
selected Configuration Space in a Configuration Table format.
Go to Trigger
Repositions the display to show the first packet following the
trigger event.
Go to Selected
Packet
Repositions the display to a specific packet, Link or Split transaction
of PCI Express protocol or NVME, PQI, AHCI protocol and ATA
command transactions number.
Go to Packet
Allows searching for specific link events packets or time.
Go to Time
Repositions the display to specific timestamp.
Go to Marker
Repositions the display to a previously marked packet, Link, Split,
NVME, PQI, AHCI or ATA command transactions.
Go to
Allows searching for specific link events: TLP Type, DLLP Type,
Ordered Set, Link Event, Traffic Class, DLLP Virtual Channel,
TLP Virtual Channel, Direction, Speed, Link Width, Requester ID,
Completer ID, Data Lengths, Errors.
