Summit T3‐16 PCI Express Multi‐Lane Protocol Analyzer User Manual

37

Using the Menus

 Teledyne  LeCroy

4.5.8

Tools Menu

Zoom Out

Zoom out decreases the size of the displayed elements.

Wrap

Wraps displayed packets within the window.

Synchronize
Trace View
With Other
Views

Synchronizes the Trace view with other views.

FC Credits

Toggles a display for tracking Flow Control Credit update and
consumption on a PCI Express link.

FC Credits
Setup

Allows you to customize the display for tracking Flow Control
Credits.

Compact View

Toggles compacting of the Link Training sequence to analyze CATC
Trace data faster or no compacting to display more data.

Packet Level

View the current recording at the Packet Level.

Link
Transaction
Level

View the current recording at the Link Transaction Level.

Split
Transaction
Level

View the current recording at the Split Transaction Level.

NVM
Transaction
Level

View the current recording at the NVM Transaction Level.

PQI
Transaction
Level

View the current recording at the PQI Transaction Level.

ACHI
Transaction
Level

View the current recording at the ACHI Transaction Level.

ATA
Transaction
Level

View the current recording at the ATA Transaction Level.

Configuration
Space Editor

Displays the Configuration Space Editor dialog which allows you to
either create a new Configuration Space File or open an existing
Configuration Space File.
