LabMaster 10 Zi Oscilloscopes

32

LM10Zi-GSM-E Rev A

External Display Setup

Setting up the Zi-EXTDISP-15External Display involves making DVI-D and
USB connections and some touch screen selections. The USB connection
is a "hot swap," so there's no need to restart the instrument once
you've connected.

1.

With your system powered down, attach the Zi-EXTDISP-15
power cord
from the power port of the PCIe card on the back of
the Zi-EXTDISP-15 monitor to an AC socket.

2.

Attach the provided DVI-D cable from the back of the Master
Control Module to the DVI-D port on the Zi-EXTDISP-15 monitor.

3.

Attach the provided USB cable (where applicable) from the back
of the Master Control Module to a USB port on the Zi-EXTDISP-15
monitor.

4.

Turn on the oscilloscope.

5.

When the instrument has finished booting, touch Display →
Display Setup...
from the menu bar.

6.

In the Second Monitor Configuration section of the Display
dialog, touch Open Monitor Control Panel.

7. Use the

Intel® Graphics Media Accelerator Driver

to adjust

your external monitor settings.
