Getting Started Manual
LM10Zi-GSM-E Rev A 99

MultiStage Triggers - varied forms of triggers including Cascaded,
QualFirst, and Qualified allowing varied combinations of triggers
and trigger stages.

Serial Triggers - provide serial data protocol specific triggering for
a wide variety of standards.
Trigger Types
A set of standard trigger types is available for selection. These triggers
are basic waveform features or conditions such as a positive or negative
slope and are available on all oscilloscopes, along with tools like
Software Assisted Trigger and Trigger Scan.
There are more sophisticated triggers for setting complex conditions.
These include Smart Triggers, Serial Trigger, Measurement Triggers,
and MultiStage Triggers.
Edge
A simple trigger, Edge trigger is activated by basic waveform
features or conditions such as positive or negative slope, and
holdoff.
NOTE: Up to 15 GHz bandwidth is available while Edge Triggering
(provided no holdoff is selected).
Width
Width trigger allows you to define a positive- or negative-
going pulse width bounded by a voltage level, above or below
an occurring trigger. Or you can specify a pulse width and voltage range,
within or outside an occurring trigger.
Pattern (Logic)
Logic trigger enables triggering on a logical combination
(pattern) of five inputs: CH1, CH2, CH3, CH4, and AUX
(sometimes referred to as EXT on legacy oscilloscope
models). You have a choice of four Boolean operators (AND, NAND, OR,
