Selecting Measure Modes

1.

Touch Measure → Measure Setup... on the menu bar.

2.

Under Measure Mode, select the Std Vertical or Std Horizontal
buttons.

NOTE: You can customize parameters by touching My Measure.
Learn more in Customizing a Parameter (on page 1).

3.

Touch inside the Source data entry control and choose a source
for which the measurements should apply.

Help Markers

Help Markers clarify parameter measurements by displaying movable
cursors and a visual representation of what is being measured. For the
at level parameters, Help Markers make it easier to see where your
waveform intersects the chosen level. This feature also displays the
hysteresis band that you have set about that level.

You also have the option, by means of an Always On checkbox, to leave
the Help Markers displayed after you have closed the Help Markers
setup dialog.
