LabMaster 10 Zi Oscilloscopes

116

LM10Zi-GSM-E Rev A

5.

Touch the Axis labels checkbox to permanently display the values
of the top and bottom grid lines (calculated from volts/div) and
the extreme left and right grid lines (calculated from the
timebase).

6.

Choose a line style for your trace: solid Line or Points as follows:

7.

Touch inside the trace Intensity data entry control if you want to
change the value. Enter a value from 0 to 100.

NOTE: Touch the Monitor tab for external monitor display
settings.
