Getting Started Manual

LM10Zi-GSM-E Rev A

Front of 10-xxZi Acquisition Module

Number and Description

1. 2.92 mm Inputs

2. 1.85 mm Inputs

(>36 GHz models)

3. AUX IN

4. AUX OUT

5. Channel Number

Indicators

6. Channel ON/OFF

Buttons

7. Fast Edge Output

8. Ground connection

for wrist strap

PLEASE NOTE THE FOLLOWING:



If your system runs multiple Acquisition Modules, for optimal
channel access and convenience, Teledyne LeCroy recommends
stacking the modules on top of each other on your bench, inside
Teledyne LeCroy's available OC910 oscilloscope cart or inside of
your own rack (modules must be specifically ordered for rack
mounting from the Teledyne LeCroy factory).
