Turning On Markers
1.
Touch Measure → Measure Setup... on the menu bar.
2.
Select mode Std Vertical, Std Horizontal, or My Measure.
3.
Touch the Show All button (as follows) to display Help Markers
for every parameter being measured on the displayed waveform
(C2 in the previous examples).
4.
Touch a Px tab for any listed parameter; it doesn't matter which.
5.
On the Parameter dialog, touch Help Markers and select either:
Simple - produces cursors and Measure Gate posts. The
gate posts are independently placeable for each
parameter.
Detailed - produces cursors, Measure Gate gate posts, a
label identifying the parameter being measured, and a
level indicator and hysteresis band for "at level"
parameters.
NOTE: The choice of Simple or Detailed is applied to all
parameters at the same time. That is, if you choose Simple
markers for one parameter, all parameters are then displayed in
this mode.
6.
Touch the Always On checkbox if you want to continuously
display Help Markers for this parameter.
Turning Off Markers
1.
Touch the Clear All button to turn off Help Markers for all
parameters.
2.
Turn off Help Markers for individual parameters by touching the
Px tab for the parameter in question. Then uncheck the
AlwaysOn checkbox. When you close this dialog, the Help
Markers for this parameter are no longer shown.
