LabMaster 10 Zi Oscilloscopes
122 LM10Zi-GSM-E Rev A
Zooming Waveforms
Zooming Waveforms Overview
You can magnify a selected region of a waveform using the Zoom
function. On Zi model oscilloscopes, you can display up to four Zoom (Z1
- Z4) and eight Math Zoom traces (F1 - F8). You can zoom:

A single channel - covered in To Zoom a Single Channel (on page
123).

A math or memory trace

Multiple waveforms at once - covered in To Zoom Multiple
Waveforms Quickly (on page 126).

Segments in a sequence - found in Sampling Modes → Sequence
Sampling Mode (on page 76)
You can also use the Multi-Zoom Math function to create time-locked
zoom traces for selected waveforms. For more information, refer to
Math → Multi-Zoom).
At any time, you can zoom a portion of a channel waveform or
Memory/Math function trace by touching and dragging a rectangle
around any part of the input waveform, see the To Zoom by Touch-and-
Drag (on page 125) topic. The zoom trace will size itself to fit the full
width of the grid. The degree of magnification, therefore, will depend
on the size of the rectangle that you draw.
You can also use the front panel Q
UICK
Z
OOM
button to create multiple
zooms, one for each displayed input channel. For more information, see
the To Zoom Multiple Waveforms Quickly (on page 126) topic.
