LabMaster 10 Zi Oscilloscopes

126

LM10Zi-GSM-E Rev A

Quickly Zooming Waveforms and
Multiple Waveforms

Quickly create a Zoom trace by either pressing the front panel Zoom
button or touching the Zoom button on the respective channel dialog.

Turning Off Zoom

Turn off a Zoom by either pressing the front panel Zoom button again.

OR

On the corresponding Zoom dialog, touch the Trace On checkbox to
remove the check mark and disable the zoom trace.
