Getting Started Manual
LM10Zi-GSM-E Rev A 189
5. Touch inside the File Name data entry control and provide a
name for the display image using your preferred input control
method. Additional information on using the touch screen
controls can be found in the Dialog Area.
6. Touch inside the Directory data entry control and provide the
folder path for the resulting printout, or touch the Browse button
and navigate to the folder.
7. Touch the Hardcopy Area control to choose which part of the
screen you want to print.

Grid Area Only if you do not need to print the dialog area
and you only want to show the waveforms and grids.

DSO window if you want to print the dialogs with the
waveforms and grids.

Full Screen if you want to print the entire screen.
8. Touch the Print Now button.
C
LIPBOARD
The Clipboard selection on the Hardcopy tab saves the screen image on
the clipboard so you can paste a file into another application (like
Microsoft Word, for example).
NOTE: Once you have configured your Clipboard settings from the
Hardcopy dialog (using the procedure below), you can use front panel
Print flyout menu functions like Save Screen To Clipboardand Print .
The instrument automatically uses the additional clipboard settings to
save the screen image to the clipboard.
Front Panel Method
Press the Print front panel button. Then, touch the Save Screen To
Clipboard button from the Print flyout menu.
