Teledyne LeCroy LabMaster 10Zi Getting Started Manual User Manual
Page 128
Getting Started Manual
LM10Zi-GSM-E Rev A
121
Color Persistence - The button behaves the same way as Analog.
However, the grid display shows a color waveform where red
indicates most frequent occurrences while blue denotes the less
frequent.
Instead of using the knob, you can provide values for Intensity (same
control on Display and Persistence dialogs) or Saturation controls.
