Getting Started Manual
LM10Zi-GSM-E Rev A 119
4. Touch inside the Saturation data entry control and provide a
whole number integer.
5. Touch inside the Persistence time data entry control and make
a selection from the pop-up menu.
Setup Each Input Channel Individually
1. Touch the Per Trace button.
2. Touch one of the persistence mode buttons next to an input
channel.
To refine the settings, touch the tab to set up persistence for
that channel.
3. Touch one of the mode buttons.
4. Touch the Show last trace checkbox if you want the last trace
displayed.
5. Touch inside the Saturation data entry control and enter a
whole number integer,.
6. Touch inside the Persistence time data entry control and make
a selection from the pop-up menu.
7. If you want to return all input channel setups to their default
settings, touch the Reset All button.
