Page 19
LabMaster 10 Zi Oscilloscopes
12
LM10Zi-GSM-E Rev A
Front of MCM-Zi Master Control Module
The MCM-Zi Master Control Module includes Controls, Display, CPU,
and ChannelSync Clock Architecture. All acquisition capability is
contained in separate Acquisition Modules.
Number and Description
1. Power
Button
2. Fast Edge
Output
3. Host USB Ports
4. Detachable Front Panel
Control
5. Front Panel Control
Release Switch
