Getting Started Manual
LM10Zi-GSM-E Rev A 155
Actions Dialog
Various configurations can be made to all or some of your Pass/Fail
conditions using the Actions dialog.
By touching the Stop Test checkbox in the Actions dialog, you can set up
the test to end after a predetermined number of sweeps that you
decide.
You can also decide the actions to occur upon your waveforms' passing
or failing, by selecting one or all of the following:

Stop

Audible alarm

Print image of display

Emit pulse (if available)

Save waveform
The Pulse checkbox causes a pulse to be output through
the Aux Out connector at the front of the oscilloscope.
This pulse can be used to trigger another oscilloscope.
You can set the amplitude and width of the pulse as described in
Auxiliary Output Signals.
Depending on your oscilloscope model, you can configure up to 8
pass/fail conditions. The Boolean conditions to determine if your
waveform passes are as follows:
