Teledyne LeCroy X-STREAM OSCILLOSCOPES Remote Control User Manual
Page 94
P
A R T
T
W O
:
C O M M A N D S
88
ISSUED: February 2005
WM-RCM-E Rev D
S
HORT
F
ORM
L
ONG
F
ORM
W
HAT THE
C
OMMAND OR
Q
UERY
D
OES
CURSOR
—
T
O
P
ERFORM
M
EASUREMENTS
CRMS CURSOR_MEASURE
Specifies the type of cursor or parameter measurement for display.
CRST CURSOR_SET
Allows positioning of any cursor.
CRVA? CURSOR_VALUE?
Returns the values measured by the specified cursors for a given trace.
CRS CURSORS
Sets the cursor type.
OFCT OFFSET_CONSTANT
Sets offset to be constant in divisions or volts.
PARM PARAMETER
Controls the parameter mode.
PACL PARAMETER_CLR
Clears all current parameters in Custom and Pass/Fail modes.
PACU PARAMETER_CUSTOM
Controls parameters with customizable qualifiers.
PADL PARAMETER_DELETE
Deletes a specified parameter in Custom and Pass/Fail modes.
PAST? PARAMETER_STATISTICS
Returns parameter statistics results.
PAVA? PARAMETER_VALUE?
Returns current value(s) of parameter(s) and mask tests.
PF PASS_FAIL
Sets up the Pass / Fail system.
PFDO PASS_FAIL_DO
Defines outcome and actions for the Pass/Fail system.
PECS PER_CURSOR_SET
Positions one of the six independent cursors.
DISPLAY
—
T
O
D
ISPLAY
W
AVEFORMS
DISP DISPLAY
Controls the oscilloscope display screen.
DTJN DOT_JOIN
Controls the interpolation lines between data points.
GRID GRID
Specifies grid display in single, dual or quad mode.
HMAG HOR_MAGNIFY
Horizontally expands the selected expansion trace.
HPOS HOR_POSITION
Horizontally positions the intensified zone’s center on the source trace.
INTS INTENSITY
Controls the brightness of the grid on the instrument screen.
MSG MESSAGE
Displays a string of characters on the instrument screen for a short time.
PERS PERSIST
Enables or disables the Persistence Display mode.
PECL PERSIST_COLOR
Controls color rendering method of persistence traces.
PELT PERSIST_LAST
Shows the last trace drawn in a persistence data map.
PESA PERSIST_SAT
Sets the color saturation level in persistence.
PESU PERSIST_SETUP
Selects display persistence duration in Persistence mode.
TRA TRACE
Enables or disables the display of a trace.
VMAG VERT_MAGNIFY
Vertically expands the specified trace.
VPOS VERT_POSITION
Adjusts the vertical position of the specified trace.
ET-PMT — E
LECTRICAL TELECOMM
CUAP CUSTOM_APPLICATION
Toggles between Mask Tester mode and oscilloscope mode.
CU_OPT? CUSTOM_OPTIONS?
Returns installed custom options.
MTAT MT_ATTENUATION
Sets cable attenuation factor for 2M_TP, 2M_COAX, 8M, 34M, 139M,
156M.
MTFA? MT_FAIL_ACTION
Sets fail actions.
MTOF MT_OFFSET
Sets the offset for STM-1E, STS-3E, and 139M.
MTOP? MT_OPC?
Returns state of last operation.
