P A R T T W O : C O M M A N D S
214
ISSUED: February 2005 WM-RCM-E Rev D
SAVE/RECALL SETUP
*RCL
Command
DESCRIPTION The *RCL command sets the state of your instrument, using one
of the six non-volatile panel setups (Panel 1 to Panel 6), by
recalling the complete front panel setup of the oscilloscope.
Entering panel setup “0” corresponds to the default panel setup.
The *RCL command produces an effect the opposite of the *SAV
command.
If the desired panel setup is not acceptable, the EXecution error
status Register (EXR) is set and the EXE bit of the standard
Event Status Register (ESR) is set.
COMMAND SYNTAX
*RCL
: = 0 to 6
EXAMPLE (GPIB) The following instruction recalls your instrument setup previously
stored in panel setup 3:
CMD$=“*RCL 3”: CALL IBWRT(SCOPE%,CMD$)
RELATED COMMANDS PANEL_SETUP, *SAV, EXR
