P A R T T W O : C O M M A N D S
192
ISSUED: February 2005 WM-RCM-E Rev D
: = {POS, NEG, ALL}
, , : = 1 to 99 if level is specified in percent
(PCT), or
, , : = Level in in the units of
the waveform.
: = -100 PCT to 100 PCT
: = 10 to 1e9 Hz (Narrow Band center frequency)
: = 0.01 to 8 divisions
: = 1e-9 to 0.001 seconds
: = {ADD, SUB, MUL, DIV} *
: = 1 to 100
: = 0 to 100 percent
= {PCT, DEG, RAD}
= {OFF, ON}
QUERY SYNTAX
PArameter_CUstom?
RESPONSE FORMAT PArameter_Custom
,,[,,...]
AVAILABILITY : = {C3, C4} only on four-channel oscilloscopes.
EXAMPLE 1 DTLEV
Command Example:
PACU 2,DTLEV,C1,POS,345E-3,C2,NEG,-789E-3
Query/Response Examples:
PACU? 2 returns:
PACU 2,DTLEV,C1,POS,345E-3,C2,NEG,-789E-3
PAVA? CUST2 returns:
C2:PAVA CUST2,789 NS
* For Parameter Math option
