Remote Control Commands and Queries

WM-RCM-E Rev D

ISSUED: February 2005

257

WAVEFORM

TRANSFER

WAVEFORM_SETUP, WFSU

Command/Query

DESCRIPTION

The WAVEFORM_SETUP command specifies the amount of data in
a waveform to be transmitted to the controller. The command

controls the settings of the parameters listed below.

N

O T A T I O N

FP

first point

NP

number of points

SN

segment number

SP

Sparsing

Sparsing (SP):

The sparsing parameter defines the interval between data points. For

example:

SP = 0

sends all data points

SP = 1

sends all data points

SP = 4

sends every 4th data point

Number of points (NP):

The number of points parameter indicates how many points should
be transmitted. For example:

NP = 0

sends all data points

NP = 1

sends 1 data point

NP = 50

sends a maximum of 50 data points

NP = 1001

sends a maximum of 1001 data points

First point (FP):

The first point parameter specifies the address of the first data point
to be sent. For waveforms acquired in sequence mode, this refers to

the relative address in the given segment. For example:

FP = 0

corresponds to the first data point

FP = 1

corresponds to the second data point

FP = 5000

corresponds to data point 5001
