Remote Control Commands and Queries

WM-RCM-E Rev D

ISSUED: February 2005

149

FUNCTION

FUNCTION_RESET, FRST

Command

DESCRIPTION

The FUNCTION_RESET command resets a waveform processing
function. The number of sweeps will be reset to zero and the process

restarted.

COMMAND SYNTAX

: Function_ReSeT

EXAMPLE (GPIB)

: = {F1, F2, F3, F4, F5, F6, F7, F8, TA, TB, TC, TD}
TA through TD are included for backward compatibility with

software designed for earlier LeCroy instruments. They are not used
in responses to queries.

Assuming that Trace F1 has been defined as the summed average of
Channel 1, the following will restart the averaging process:

CMD$=“F1:FRST”: CALL IBWRT(SCOPE%,CMD$)

RELATED COMMANDS

INR
