Remote Control Commands and Queries
WM-RCM-E Rev D ISSUED: February 2005
209
CURSOR
PER_CURSOR_SET, PECS
Command/Query
DESCRIPTION The PER_CURSOR_SET command allows you to position one or
more of the six independent cursors at a given grid location. Cursors
must be turned on for the PECS? query to work.
NOTATION
HABS Horizontal absolute VABS Vertical absolute
HDIF Horizontal difference VDIF Vertical difference
HREF Horizontal reference VREF Vertical reference
COMMAND SYNTAX :PEr_Cursor_Set
,[,,,…,,
>]
:={C1, C2, C3, C4, F1 through F8, M1, M2, M3, M4, TA,
TB, TC, TD}. TA through TD are included for compatibility with
existing software for earlier instruments. These four mnemonics will
not be used in responses to queries.
QUERY SYNTAX :PEr_Cursor_Set?
EXAMPLE(GPIB) The following instruction positions the HREF and HDIF cursors at
+2.6 DIV and +7.4 DIV respectively, using Channel 2 as a reference:
CMD$=”C2:PECS HREF,2.6 DIV,HDIF,7.4 DIV”
CALL IBWRT(SCOPE%,CMD$)
RELATED COMMANDS CURSOR_MEASURE, CURSOR_SET, PER_CURSOR_VALUE
