Remote Control Commands and Queries

WM-RCM-E Rev D

ISSUED: February 2005

247

ACQUISITION

TRIG_SLOPE, TRSL

Command/Query

DESCRIPTION

The TRIG_SLOPE command sets the trigger slope of the specified
trigger source.

The TRIG_SLOPE? query returns the trigger slope of the selected
source.

COMMAND SYNTAX

: TRig_SLope
: = {C1, C2, C3, C4, LINE, EX,
EX10,ETM10}

: = {NEG, POS}

QUERY SYNTAX

: TRig_SLope?

RESPONSE FORMAT

: TRig_SLope

AVAILABILITY

: = {C3, C4} only available on four-channel

oscilloscopes.

EXAMPLE (GPIB)

The following instruction sets the trigger slope of Channel 2 to

negative:

CMD$=“C2:TRSL NEG”: CALL IBWRT(SCOPE%,CMD$)

RELATED COMMANDS

TRIG_COUPLING, TRIG_DELAY, TRIG_LEVEL,
TRIG_MODE, TRIG_SELECT, TRIG_SLOPE
