Remote Control Commands and Queries
WM-RCM-E Rev D ISSUED: February 2005
119
CURSOR
CURSOR_VALUE?, CRVA?
Query
DESCRIPTION The CURSOR_VALUE? query returns the values measured by the
specified cursors for a given trace. (The PARAMETER_VALUE?
query is used to obtain measured waveform parameter values.)
There are important differences in the function of this command
between X-Stream instruments and earlier LeCroy instruments.
The keyword ALL should NOT be used, neither should multiple
keywords. If they are used, the word UNDEF will be returned.
For the CRVA? query to work, the specified trace MUST be visible,
and the current cursor mode must be the same as in the query. If it
is not the same, UNDEF will be returned.
N OTATION
HABS
horizontal absolute
HREL horizontal relative
QUERY SYNTAX : CuRsor_VAlue? []
: = {F1, F2, F3, F4, F5, F6, F7, F8, TA, TB, TC, TD, C1,
C2
, C3, C4} TA through TD are for compatibility with existing
software with earlier instruments. These four mnemonics are not
returned by queries.
: = {HABS, HREL, VABS, VREL }
RESPONSE FORMAT : CuRsor_VAlue HABS,,
: CuRsor_VAlue HREL,,,
,,. The dV/dt value
is displayed in the appropriate trace label box.
: CuRsor_VAlue VABS,
: CuRsor_VAlue VREL,
For horizontal cursors, both horizontal as well as vertical values are
given. For vertical cursors only vertical values are given.
