background image

Remote Control Commands and Queries

WM-RCM-E Rev D

ISSUED: February 2005

201

A

VAILABLE WITH

XMATH

O

PTION

AVG

Histogram mean

MODE

Histogram mode

FWHM

Histogram FWHM

NBPH

Narrow band phase

FWXX

Histogram FW peak

NBPW

Narrow band power

HAMPL

Histogram amplitude

PKS

Histogram no of peaks

HBASE

Histogram base

PCTL

Histogram percentile

HIGH

Histogram right bin

POPATX

Histogram bin population

HMEDI

Histogram median

RANGE

Histogram range

HRMS

Histogram RMS

SIGMA

Histogram standard dev

HTOP

Histogram top

TOTP

Histogram total pop

LOW

Histogram left bin

XAPK

Histogram Nth peak

MAXP

Histogram max pop

P

ARAMETER

C

OMPUTATION

S

TATES

AV

averaged over several (up to 100) periods

OF

Signal partially in overflow

GT

greater than given value

OK

Deemed to be determined without problem

IV

invalid value (insufficient data provided)

OU

Signal partially in overflow and underflow

LT

less than given value

PT

Window has been period truncated

NP

no pulse waveform

UF

signal partially in underflow

M

ASK

T

EST

N

AMES

ALL_IN

all points of waveform inside

mask (TRUE = 1, FALSE = 0)

SOME_IN

some points of waveform inside mask

(TRUE = 1, FALSE = 0)

ALL_OUT

all points of waveform outside
mask (TRUE = 1, FALSE = 0)

SOME_OUT

some points of waveform outside mask
(TRUE = 1, FALSE = 0)
