P A R T T W O : C O M M A N D S
158
ISSUED: February 2005 WM-RCM-E Rev D
STATUS
INR?
Query
DESCRIPTION The INR? query reads and clears the contents of the INternal state
change Register (INR). The INR register (table below) records the
completion of various internal operations and state transitions.
I NTERNAL S TATE R EGISTER S TRUCTURE (INR)
Bit Bit Value Description
15 0 Reserved for future use.
14 16384 1 Probe was changed.
13 8192 1 Trigger is ready.
12 4096 1 Pass/Fail test detected desired outcome.
11 2048 1 Reserved
10 1024 1 Reserved
9 512 1 Reserved
8 256 1 Reserved
7 128 1 A floppy or hard disk exchange has been detected.
6 64 1 Floppy or hard disk has become full in AutoStore Fill mode.
5 32 0 Reserved for LeCroy use.
4 16 1 A segment of a sequence waveform has been acquired in acquisition
memory but not yet read out into the main memory.
3 8 1 A time-out has occurred in a data block transfer.
2 4 1 A return to the local state is detected.
1 2 1 A screen dump has terminated.
0 1 1 A new signal has been acquired in acquisition memory and read out into
the main memory.
