Teledyne LeCroy X-STREAM OSCILLOSCOPES Remote Control User Manual
Page 254

P
A R T
T
W O
:
C O M M A N D S
248
ISSUED: February 2005
WM-RCM-E Rev D
A
UTOMATION
VBS, VBS
Command/Query
DESCRIPTION
The VBS command allows Automation commands to be sent in the
context of an existing program.
The Automation command must be placed within single quotation
marks.
The = sign may be flanked by optional spaces for clarity.
COMMAND SYNTAX
VBS
QUERY SYNTAX
VBS?
EXAMPLES with “GPIB”
Equivalents
The following instruction sets Channel 1 vertical scale to 50 mV/Div,
the time per division to 500 ns, and the grid mode to Dual:
CMD$=“VBS ‘app.Acquisition.C1.VerScale=0.05’”
CMD$ “C1:VDIV 50 MV” (GPIB equivalent)
CMD$=“VBS ‘app.Horizontal.HorScale = 500e-9’”
CMD$ “TDIV 0.5e-6” (GPIB equivalent)
CMD$=“VBS ‘app.Display.GridMode=”Dual”’
CMD$ “GRID DUAL” (GPIB equivalent)
QUERY SYNTAX
CMD$ = “VBS?
‘Return=app.Acquisition.C1.VerScale’”
