background image

-Gilderfluke & Co. Sd-50/40 Audio/Show Controller vers. 1.00 copyright 2007 DCM-

Card at 00h/__0 | DMX-512 w/258 /CS data Rxd | flash: 4 MBytes (locked)

1/4 J6 in: 00000000b | MCU in: 00000000b

A/Green: Open

B/Red: Open

C/Blue: Open

D/White: Open

GPS: 34º10'35.94"N 118º18'40.17"W alt:171m spd:12.3k hdg:123º sats:8 hdop:0.9m

set: CRoom1__.a00 | # of shows: _10 | # of channels: 236 | @ offset: __0

show: _10 CR1_LOff.sho looping @ frame _____29

sound: _15 SoundFiles playing #__0 FileName.MP3 @ 12345 sec. vol: 255/255 locked

GPS time: dst 01:23:45 Sunday January 01, 2007 sch: Sundays in May

d) DST: 02:00 2nd Sunday in March to 02:00 1st Sunday in November

u) adj. | Servo0 | Servo1 | Servo2 | Servo3 | Servo4 | Servo5 | Servo6 | n/a 7

minimum:|1.0000ms|1.0000ms|1.0000ms|1.0000ms|1.0000ms|1.0000ms|1.0000ms|1.0000ms

maximum:|2.0000ms|2.0000ms|2.0000ms|2.0000ms|2.0000ms|2.0000ms|2.0000ms|2.0000ms

a) play a sound b) stop sound o) reload defaults z) time Zone: -08:00

l) Loop show p) Play show s) Stop show e) stop at End

v) Verify shows i) show Info m) Config x) eXit

Command-

Main Menu: (Sample data: Your show and sound data will differ from what is shown.)

To redraw the screen at any time, just press the ape key or bar.

1) Header Information:

a) Gilderfluke & Company

b) product name

c) Firmware revision number

d) copyright.

3) Serial Port Information:

a) Card serial address

b)

DMX-512

,

MIDI in

or

Net Serial

data is being received through the secondary serial port.

i)

If receiving DMX, if the packets are 258 bytes in length

ii) If receiving DMX, if the packets are expected to contain a GilderChecksum

c) the amount of onboard flash memory installed

d) if the onboard flash memory has been locked or is writable.

4) The current status of:

a)

‘" J6’

input

b)

Animation ‘Virtual’ Audio Trigger Input

port that is used to trigger audio from animation data

5) The current status of the A/Green optically isolated input. Input will show whether it is ‘opened’ (no

current flowing) or ‘closed’ (current flowing through the input).

6) The current status of the B/Red optically isolated input. Input will show whether it is ‘opened’ (no

current flowing) or ‘closed’ (current flowing through the input).

7) The current status of the C/Blue optically isolated input. Input will show whether it is ‘opened’ (no

current flowing) or ‘closed’ (current flowing through the input).

Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485

Sd-50/xx Manual / October 29, 2012 2:29 PM / page 67 of 120
