Sd-50/0, Sd-50/8 or Sd-50/40 Hardware Config.

Just about all the Sd-50/8 or Sd-50/40 configuration is done using the ‘Mp3 Config.exe’ program, Se-

rial port using GilderTerm, or during the AutoDownload of the shows from PC•MACs. The only hardware
configuration options are:

1) ʻ

" J6

ʼ Internal/External Power

This switch (located on the bottom of the Sd-50/xx) is used to switch the power from the

‘" J6’

connector be-

tween an internal source, and an external source that must be fed from outside the Sd-50/xx. For a Sd-50/0, this is
the trigger input to the .Mp3/.wav player, and either position can be used as determined by your application. For
the Sd-50/xx, this is also the first or last Show Control output channel. Only the ‘Internal’ position should be used.

2) RS-422/Optoisolated

This switch (located on the bottom of the Sd-50/8 or Sd-50/40) is used to switch the

DMX-512/MIDI serial port

between using RS-422 input signal levels to an optoisolated current loop. If receiving

DMX-512

, you must use the

‘RS-422’ setting. For

MIDI in

, you must use the ‘optoisolated’ position. For

Net Serial

or

IR Trigger modes

, you can

use either position, but ‘RS-422’ is normally used unless you need to optically isolate the input.

3) Right Volume Control
4) Left Volume Control

These two potentiometers (located on the front of the Sd-50/xx) are used to adjust the audio level for the two

outputs from the Sd-50/xx. They control both the line level outputs, and the on board amplifier’s output levels.

The volume control pots on the front of the Sd-50/xx’s are downstream of the

electronic volume limits

set inside

the ‘Mp3 Config.exe’ program. This allows the volume to be adjusted to anywhere BELOW the limit set in the ‘Mp3
Config.exe
’ program.

In most applications, you will use the

electronic volume limits

set inside the ‘Mp3 Config.exe’ program to set

the MAXIMUM possible output from the Sd-50/xx’s. This should be set to a level which is loud, but not so loud that
it will destroy the speakers and other downstream gear (or listeners).

Use a small ‘trimmer’ screwdriver to adjust the volume control pots.

The the volume control pots are smaller than you.

Do not use a big screwdriver on them.

Do not apply too much force.

They will break!
