e)! IR Trigger Mode
and
.
Data output from the DMX-512/MIDI serial port will be buffered and repeated, but otherwise an unaltered
version of what is received on the input.
When this mode is enabled, it sets the DMX-512/MIDI port to 1200 baud, and listens for commands
transmitted by the Gilderfluke & Company IR transmitter and receiver. The IR Remote is typically used to
trigger an animation or sound system mounted on a vehicle, turntable, or other installation where wires
can’t be used.
The connections to the IR Remote Receiver are as follows (view is facing end of cable with latch up):
NAME
COLOR
SIGNAL FUNCTION
LEFT
Ground
WHITE
Ground
n/c
BLACK
no connection
n/c
RED
no connection
- TxD
GREEN
- DMX-512/MIDI Input
+ TxD
YELLOW
+ DMX-512/MIDI Input
RIGHT
Ground
BLUE
Ground
In addition to these connections, the IR Receiver requires a seven to twenty-four volt DC (Direct Cur-
rent) power supply connection. This is normally attached to the two pads marked “+” and “-” on the receiver.
A jumper option allows you to bring this in through the blue wire on the RJ-11 connector.
The IR Transmitter has an eight position dipswitch which sets which show it selects. The lower nibble
of the address is set with the first four switches, and the upper nibble is set with the last four. Valid show
numbers are 01h through FFh:
Lower nibble
of Address
Switch #1
Switch #2
Switch #3
Switch #4
x0h
x1h
x2h
x3h
x4h
x5h
x6h
x7h
x8h
x9h
xAh
xBh
xCh
xDh
xEh
xFh
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
ON
OFF
ON
OFF
ON
OFF
OFF
ON
ON
OFF
ON
ON
ON
OFF
OFF
OFF
OFF
ON
ON
OFF
OFF
ON
OFF
ON
OFF
ON
ON
ON
OFF
ON
OFF
OFF
ON
ON
ON
OFF
ON
ON
OFF
ON
ON
ON
ON
ON
ON
ON
Upper nibble
of Address
Switch #5
Switch #6
Switch #7
Switch #8
0xh
1xh
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
