If any of the pins on the ‘" J6’ output from a Sd-50/8 or Sd-50/40 are being used a ServoMotor PWM
outputs , the corresponding output LEDs will have a steady glow.
A Sd-50/0 has eight optically isolated trigger inputs which can be used to select, start shows and
SoundFiles and change the audio levels of the audio half of the Sd-50/0 player. The only output channel on
a Sd-50/8, and the last output channel on a Sd-50/40 are shared with these audio trigger inputs. Normally
these are not used to trigger the audio on a Sd-50/8 or Sd-50/40. The ‘virtual’ MPU trigger inputs from the
Show Control half of the Sd-50/8 or Sd-50/40 are normally used instead. This leaves these eight outputs
free to be used as outputs on most Sd-50/8 and Sd-50/40 applications.
12)! Input Open (Sd-50/0)
This LED flashes briefly to show that an opening edge has occurred on any of the eight ‘ " J6 ’ inputs.
13)! Input Close (Sd-50/0)
This LED flashes briefly to show that a closing edge has occurred on any of the eight ‘ " J6 ’ inputs.
