Defaults for Sd-50/0s, Sd-50/8s and Sd-50/40s

Although almost everything can be adjusted on a Sd-50/xx, almost all applications will be able to use

the ‘default’ settings. There are a number of ways to get a Sd-50/xx to load to the default settings:

a) In the ‘Mp3 Config.exe’ program, you can select the type of player you are using from the ‘player type’

menu at the top of the window. Under the Edit menu, select ‘Reset Everything to defaults’. Save the new
configuration to the Sd/MMC flash card you will be using. When you move this Sd/MMC flash card to the
Sd-50/xx, it will load this configuration.

b) If you have a Sd/MMC flash card inserted in the Sd-50/xx, but that card does not have a Sd-50.cfg file on

it, the Sd-50/xx will create a default audio configuration. These defaults will only affect the .Mp3/.wav
player
. The settings for the animation playback can be adjusted from using GilderTerm through the Sd-50/
xx’s
serial port. Once you have entered the configuration mode for the Sd-50/xx, you can select the ‘reload
defaults’ command to reload the defaults for the animation playback too. Changes you make in the configu-
ration through the serial port and GilderTerm will ‘stick’ until you change them again, or you insert a card
with a Sd-50.cfg file loaded on it. The Sd-50/xx will load any Sd-50.cfg file as soon as it finds one.

Sd-50/0 (audio only) Defaults

Volume to defaults

. All sounds do

nothing at end

.

Play Lists

unused.

Amplifier Enabled

. The Animation ‘Virtual’

Audio Trigger Input which is used to trigger SoundFiles from the Show Control data is entirely unused (all bits set to
‘Unused’).

The

‘" J6’ Trigger Inputs

set as following:

a) If there are Zero SoundFiles in the Sounds folder, the

‘" J6’ Trigger Inputs

is set as follows:

The

‘" J6’ Trigger Inputs

are unused. All bits set to ‘Unused’.

b) If there are between one and eight SoundFiles in the Sounds folder, the

‘" J6’ Trigger Inputs

is set

for ‘Direct Selection’ of the SoundFiles: Bit #0=SoundFile 1, bit #1=SoundFile 2, bit #2=SoundFile
3, bit #3=SoundFile 4, bit #4=SoundFile 5, bit #5=SoundFile 6, bit #6=SoundFile 7, bit #7=Sound-
File 8.

b.1)

If seven or less SoundFiles are found, then the

‘" J6’ Trigger Inputs

bit #7 becomes

‘Stop Now’.

b.2)

If six or less SoundFiles are found, then the

‘" J6’ Trigger Inputs

bit #6 becomes full

mute in one second on closing, and unmute in one second upon opening.

b.3)

If five or less SoundFiles are found, then the

‘" J6’ Trigger Inputs

bit #5 becomes half

mute in one second on closing, and unmute in one second upon opening.

b.4)

If four or less SoundFiles are found, then the

‘" J6’ Trigger Inputs

bit #4 becomes un-

mute in one second on closing.

b.5)

If three or less SoundFiles are found, then the

‘" J6’ Trigger Inputs

bit #3 becomes

mute in one second on closing.

b.6)

If two or less SoundFiles are found, then the

‘" J6’ Trigger Inputs

bit #2 becomes half

mute in one second on closing.

c) If there are nine or more SoundFiles in the Sounds folder, the

‘" J6’ Trigger Inputs

is set for binary

selection of the SoundFiles: Bits 0-? are used to binary address the available SoundFiles.
