to 48K per second are supported.

• Amazingly powerful 100 Watt Stereo Class-D Amplifier (fifty watts/channel). This amplifier has

the output power of a typical 400 to 500 Watt linear amplifier, but without the high current
draw and waste heat. In most applications, this amplifier means that all you need to add are
appropriate speakers, a Sd/MMC flash card and a power supply to get up and running.

• Up to 255 different SoundFiles can be selected and played.

• Sound capacity is only limited by the size of the Sd/MMC flash card installed. As of this writ-

ing, Sd cards of up to four GBytes have been tested with the Sd-50/xxʼs. Using typical
.mp3 data rates, you can put about two full day’s worth of sound (yes, 48 hours!) on a single
four GByte Sd card. Larger capacity Sd cards are on the way, and should work just as well,
and hold even more sound.

• Audio data is stored in standard

Sd/MMC flash cards

. You move the Sd/MMC flash card to

your computer for high speed ‘drag-n-drop’ downloading. Some computers have Sd/MMC
slots built in. Others will need to use a USB-to-Sd/MMC adapter. In either case, your Macin-
tosh or Windows-based computer will mount the Sd/MMC flash card as a ‘removable Drive’.
You copy your sound and animation files to the Sd/MMC flash card by just drag-n-dropping it,
just as you would copy any file from one folder to another.

• Two line level outputs (RCA Jacks) for attaching external amplifiers.

• All configuration is done through a user friendly Windows-based ‘

Mp3 Config.exe

program.

You can set the volume, EQ, and what each of the trigger inputs does. Eight of the

inputs

are

from the outside world through optoisolators, The other eight

inputs

come directly from the

Show Control side of the Sd-50/8 or Sd-50/40, if these options are installed. Any of the
inputs can be used to ramp audio to preset levels, select and play specific SoundFiles or se-
lect SoundFiles from a preset list or randomizer. Shows can be selected directly by an input,
or using a binary pattern to allow access to all 255 different possible audio files.

• Screwdriver-accessible

volume controls

. These make it easy to make final adjustments in the

output level of the Sd-50s. Additional

‘software’ volume

controls set up through the ‘Mp3

Config.exe’ program allow you to set ‘limits’, so the volume can not be turned too high using
these pots.

Mounts

stand alone, in 2-3/4” Augat Snap Track, or up to ten in a

Sd-50/CC10 cage

(Sd-50/

0 only). Using optional brackets, mounts on most flavors of DIN rails.

• The Sd-50/xx will run from

power supplies

with output voltages between twelve to twenty-four

volts DC. The Sd-50/xxʼs can even be run from batteries! For maximum output with the
onboard amplifier, use twenty-four volts, and add approximately 100 Watts (for amplifier) plus
your loads when selecting your power supply. Both screw terminal and 2.1 mm power con-
nections are available.
