DVS 510 Series • Remote Configuration and Control
58
Command
ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Picture Controls (continued)
Contrast
Specific value
E
X1%
CONT
}
Cont
X!
*
X1%
]
Set the contrast level to
X1%
.
Increment up
E
+
CONT
}
Cont
X!
*
X1%
]
Select the next higher contrast level.
Increment down
E
–
CONT
}
Cont
X!
*
X1%
]
Select the next lower contrast level.
View contrast setting
E
CONT
}
X1%
]
View the current contrast setting.
Brightness
Specific value
E
X1%
BRIT
}
Brit
X!
*
X1%
]
Set the brightness level to
X1%
.
Increment up
E
+
BRIT
}
Brit
X!
*
X1%
]
Select the next higher brightness level.
Increment down
E
–
BRIT
}
Brit
X!
*
X1%
]
Select the next lower brightness level.
View brightness setting
E
BRIT
}
X1%
]
View the current brightness setting.
Detail filter
Set detail level
E
X1%
HDET
}
Hdet
X!
*
X1%
]
Set the detail (sharpness) level to
X1%
.
Increment up
E
+
HDET
}
Hdet
X!
*
X1%
]
Increase the detail level.
Increment down
E
–
HDET
}
Hdet
X!
*
X1%
]
Decrease the detail level.
View detail value
E
HDET
}
X1%
]
Show the detail setting.
Horizontal Shift (Center)
NOTE: The horizontal and vertical shift range (
X1^
) is based on the current output resolution.
Specific value
E
X1^
HCTR
}
Hctr
X!
*
X1^
]
Set the horizontal centering to
X1^
.
Increment up
E
+
HCTR
}
Hctr
X!
*
X1^
]
Shift the displayed window right.
Increment down
E
–
HCTR
}
Hctr
X!
*
X1^
]
Shift the displayed window left.
View shift
E
HCTR
}
X1^
]
View horizontal centering value
X1^
.
Vertical Shift (Center)
NOTE: The horizontal and vertical shift range (
X1^
) is based on the current output resolution.
Specific value
E
X1^
VCTR
}
Vctr
X!
*
X1^
]
Set the vertical centering to
X1^
.
Increment up
E
+
VCTR
}
Vctr
X!
*
X1^
]
Shift the displayed window down.
Increment down
E
–
VCTR
}
Vctr
X!
*
X1^
]
Shift the displayed window up.
View shift
E
VCTR
}
X1^
]
View vertical centering value
X1^
.
Horizontal Size
NOTE: The horizontal and vertical size range (
X1&
) are based on the current output resolution.
Specific value
E
X1&
HSIZ
}
Hsiz
X!
*
X1&
]
Set the window width to
X1&
.
Increase size
E
+
HSIZ
}
Hsiz
X!
*
X1&
]
Widen the window.
Decrease size
E
–
HSIZ
}
Hsiz
X!
*
X1&
]
Narrow the window.
View
E
HSIZ
}
X1&
]
View horizontal sizing (width) value
X1&
.
NOTE: X!
= Input selection
1 through 10
X1%
= Picture adjustments
0 through 127 (for color, tint, contrast, brightness, and detail
filter)
X1^
= Horizontal and vertical shift (center)
Range depends on the current output rate.
X1&
= Horizontal and vertical size (width and height) Range depends on the current output rate.
