DVS 510 Series • Remote Configuration and Control

56

Command

ASCII Command

(Host to Scaler)

Response

(Scaler to Host)

Additional Description

Horizontal Start
Specify a value

E

X$

HSRT

}

Hsrt

X!

*

X$

]

Set the horizontal location of the first
active pixel in the active window to

X$

.

Increment value

E

+

HSRT

}

Hsrt

X!

*

X$

]

Increment the horizontal start position.

Decrement value

E

HSRT

}

Hsrt

X!

*

X$

]

Decrement the horizontal start position.

View horizontal start

E

HSRT

}

X$

]

Show the horizontal location of the first
active pixel in the active window.

Vertical Start
Specify a value

E

X%

VSRT

}

Vsrt

X!

*

X%

]

Set the vertical location of the first active
line in the active window to

X%

.

Increment value

E

+

VSRT

}

Vsrt

X!

*

X%

]

Increment vertical start position.

Decrement value

E

VSRT

}

Vsrt

X!

*

X%

]

Decrement vertical start position.

View vertical start

E

VSRT

}

X%

]

Show the vertical location of first active
line in the active window.

Pixel Phase (available only for RGB and YUVp/HDTV input signals)
Specify a value

E

X^

PHAS

}

Phas

X!

*

X^

]

Adjust the pixel phase value to

X^

.

Increment value

E

+

PHAS

}

Phas

X!

*

X^

]

Increase the pixel phase.

Decrement value

E

PHAS

}

Phas

X!

*

X^

]

Decrease the pixel phase.

View pixel phase

E

PHAS

}

X^

]

Show the pixel phase.

Total Pixels (available only for RGB and YUVp/HDTV input signals)

NOTE: The total pixels value (

X&

) is based on the current input resolution.

Specify a value

E

X&

TPIX

}

Tpix

X!

*

X&

]

Adjust total pixels to

X&

for active input.

Increment value

E

+

TPIX

}

Tpix

X!

*

X&

]

Increase the total pixels.

Decrement value

E

TPIX

}

Tpix

X!

*

X&

]

Decrease the total pixels.

View total pixels

E

TPIX

}

X&

]

Show the total pixels.

Active Pixels
Specify a value

E

X*

APIX

}

Apix

X!

*

X*

]

Adjust the active pixels value to

X*

.

Increment value

E

+

APIX

}

Apix

X!

*

X*

]

Increase the active pixels.

Decrement value

E

APIX

}

Apix

X!

*

X*

]

Decrease the active pixels.

View active pixels

E

APIX

}

X*

]

Show the active pixels.

NOTE: X!

= Input selection

1 through 10

X$

= Horizontal start

0 through 255

X%

= Vertical start

0 through 255

X^

= Pixel phase

0 to 31

X&

= Total pixels

±512 of the default value for high resolution video and ±127 for interlaced video

X*

= Active pixels

±512 of the default value for high resolution video and ±127 for interlaced video
