DS3131
30 of 174
4.4 Transmit Port Registers (2xx)
OFFSET/
ADDRESS
NAME REGISTER SECTION
0200 TP0CR Transmit Port 0 Control Register 6.2
0204 TP1CR Transmit Port 1 Control Register 6.2
0208 TP2CR Transmit Port 2 Control Register 6.2
020C TP3CR Transmit Port 3 Control Register 6.2
0210 TP4CR Transmit Port 4 Control Register 6.2
0214 TP5CR Transmit Port 5 Control Register 6.2
0218 TP6CR Transmit Port 6 Control Register 6.2
021C TP7CR Transmit Port 7 Control Register 6.2
0220 TP8CR Transmit Port 8 Control Register 6.2
0224 TP9CR Transmit Port 9 Control Register 6.2
0228 TP10CR Transmit Port 10 Control Register 6.2
022C TP11CR Transmit Port 11 Control Register 6.2
0230 TP12CR Transmit Port 12 Control Register 6.2
0234 TP13CR Transmit Port 13 Control Register 6.2
0238 TP14CR Transmit Port 14 Control Register 6.2
023C TP15CR Transmit Port 15 Control Register. 6.2
0240 TP16CR Transmit Port 16 Control Register 6.2
0244 TP17CR Transmit Port 17 Control Register 6.2
0248 TP18CR Transmit Port 18 Control Register 6.2
024C TP19CR Transmit Port 19 Control Register 6.2
0250 TP20CR Transmit Port 20 Control Register 6.2
0254 TP21CR Transmit Port 21 Control Register 6.2
0258 TP22CR Transmit Port 22 Control Register 6.2
025C TP23CR Transmit Port 23 Control Register 6.2
0260 TP24CR Transmit Port 24 Control Register 6.2
0264 TP25CR Transmit Port 25 Control Register 6.2
0268 TP26CR Transmit Port 26 Control Register 6.2
026C TP27CR Transmit Port 27 Control Register 6.2
0270 TP28CR Transmit Port 28 Control Register 6.2
0274 TP29CR Transmit Port 29 Control Register 6.2
0278 TP30CR Transmit Port 30 Control Register 6.2
027C TP31CR Transmit Port 31 Control Register 6.2
0280 TP32CR Transmit Port 32 Control Register 6.2
0284 TP33CR Transmit Port 33 Control Register 6.2
0288 TP34CR Transmit Port 34 Control Register 6.2
028C TP35CR Transmit Port 35 Control Register 6.2
0290 TP36CR Transmit Port 36 Control Register 6.2
0294 TP37CR Transmit Port 37 Control Register 6.2
0298 TP38CR Transmit Port 38 Control Register 6.2
029C TP39CR Transmit Port 39 Control Register 6.2
