DS3131
120 of 174
Register Name:
TDMAC
Register Description:
Transmit DMA Configuration
Register Address: 0874h
Bit # 7 6 5 4 3 2 1 0
Name D7 D6 D5 D4 D3 D2 D1 D0
Default
0 0 0 0 0 0 0 0
Bit # 15 14 13 12 11 10 9 8
Name D15 D14 D13 D12 D11 D10 D9 D8
Default
0 0 0 0 0 0 0 0
Note: Bits that are underlined are read-only, all other bits are read-write.
Bits 0 to 15/Transmit DMA Configuration RAM Data (D0 to D15). Data that is written to or read from the
transmit DMA configuration RAM.
