ZyWALL 10~100 Series Internet Security Gateway
7-2 DMZ Screens
Figure 7-1 DMZ
The following table describes the fields in this screen.
Table 7-1 DMZ
LABEL DESCRIPTION
DMZ TCP/IP
IP Address Type the IP address of your ZyWALL in dotted decimal notation 192.168.1.1
(factory default).
IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your
ZyWALL will automatically calculate the subnet mask based on the IP address that
you assign. Unless you are implementing subnetting, use the subnet mask
computed by the ZyWALL 255.255.255.0.
RIP Direction RIP (Routing Information Protocol, RFC1058 and RFC 1389) allows a router to
exchange routing information with other routers. The RIP Direction field controls
the sending and receiving of RIP packets. Select the RIP direction from Both/In
Only/Out Only/None. When set to Both or Out Only, the ZyWALL will broadcast
its routing table periodically. When set to Both or In Only, it will incorporate the RIP
information that it receives; when set to None, it will not send any RIP packets and
will ignore any RIP packets received. Both is the default.
